I installed Omarchy on a 2017 15-inch MacBook Pro and discovered that closing the lid could make the machine unusable. It entered suspend, but the screen stayed black when I opened it. Each failed attempt ended with a forced restart.
The final workaround was s2idle. It preserved my session and resumed, but the fans could keep running. That made it useful at a desk, not safe in a bag. The interesting part was learning why the stronger claim, “the Radeon breaks sleep,” went beyond the evidence.
The failure was below the desktop
This MacBookPro14,3 has two graphics processors: Intel HD Graphics 630 and an AMD Radeon Pro 560. Apple’s specifications for the 15-inch 2017 model confirm that graphics combination. The machine also has Apple’s T1 chip, Thunderbolt controllers, and a Samsung NVMe drive. That combination matters because suspend asks every device to enter and leave a lower power state correctly.
The first deep sleep test entered the S3 power state:
systemd-sleep: Performing sleep operation 'suspend'...
kernel: PM: suspend entry (deep)That boot never recorded PM: suspend exit. The next record was a new boot after I forced the machine off.
Later attempts resumed far enough to leave better evidence:
amdgpu: SMU load firmware failed
amdgpu: smu firmware loading failed
amdgpu 0000:01:00.0: amdgpu_device_ip_resume failed (-22)
thunderbolt: Unable to change power state from D3cold to D0
xhci_hcd: PCI post-resume error -19The Radeon clearly failed to restore its power-management firmware. Calling it the sole cause would still be inaccurate. Thunderbolt and USB host controllers failed during the same investigation, including one attempt without a recorded AMD error. The evidence pointed to a wider PCI resume problem.
One workaround targeted the wrong device
The most useful discovery was not a kernel parameter. It was a false assumption about PCI addresses.
Omarchy’s fix-suspend-nvme.sh installer script hard-coded 01:00.0 as the NVMe controller for every supported MacBook. That address is correct on models such as the MacBookPro13,1, but PCI addresses are not portable hardware identities. On this Mac, 01:00.0 was the Radeon and the Samsung NVMe controller was at 02:00.0. A separate MacBookPro14,3 hardware project records the same 02:00.0 NVMe address.
I corrected the service to target the actual NVMe controller:
ExecStart=/bin/sh -c 'echo 0 > /sys/bus/pci/devices/0000:02:00.0/d3cold_allowed'Deep sleep still failed. The address error was real, but it was not the root cause. This distinction matters in debugging: finding one incorrect configuration does not prove that fixing it solves the reported failure.
Each experiment narrowed the diagnosis
I changed one part of the suspend path at a time and checked the journal after each attempt.
| Experiment | Result | What it established |
|---|---|---|
Select s2idle in systemd | The first attempt still required a restart | Avoiding S3 alone was not sufficient in that configuration |
| Hibernate on lid close | No usable hibernation image; the next boot reported PM: Image not found (code -22) | Hibernation was not a safe fallback |
Restart systemd-logind after changing the lid rule | The active graphical session went black | Restarting logind introduced a separate failure and invalidated that test |
| Correct the NVMe PCI address | Deep sleep still failed | The bad device target was not the complete explanation |
Set pm_async=0 | Results varied; one test logged an xHCI suspend error -16 | Serial device suspension did not make S3 reliable |
Use pm_test=devices | Some failures occurred before the firmware sleep transition | At least part of the problem lived in device suspension |
Add pcie_ports=compat | AMD, Thunderbolt, and xHCI errors remained | PCIe compatibility mode did not repair resume |
Persist mem_sleep_default=s2idle | Later tests entered and exited suspend successfully | Light idle was a workable compromise |
The table also records failed ideas. That is intentional. Without it, a future test could repeat a change that already failed or mistake a coincidental successful resume for a fix.
The workaround was not a fix
Linux exposes s2idle and deep on this machine. The Linux kernel sleep-state documentation defines deep as suspend-to-RAM, which maps to ACPI S3, and s2idle as a software-based, lighter suspend state. Deep sleep powers down more hardware but could not restore it reliably on this Mac. s2idle kept more of the system active, so resume had less work to do.
I made s2idle persistent in both systemd and the kernel command line:
[Sleep]
MemorySleepMode=s2idlepcie_ports=compat mem_sleep_default=s2idleLater lid-close tests resumed successfully. The remaining cost was visible: the fans could continue running, showing that the laptop had not reached the low-power behavior I expected from S3. My operating rule became straightforward: use s2idle to preserve a session at a desk, and shut the laptop down before storing or transporting it.
I also investigated forcing Intel-only graphics with apple-gmux force_igd=y and blacklisting amdgpu. I did not test it. A mistake could leave the internal display unusable, and losing the Radeon was a larger tradeoff than I wanted for this machine.
A bounded conclusion is still useful
I did not repair deep sleep, and the logs do not support a single-device diagnosis. They do support four narrower conclusions:
- Deep S3 was unreliable on this hardware and kernel configuration
- The Radeon failed during resume, but Thunderbolt and xHCI failed too
- Correcting a genuine PCI-address mistake did not solve the broader problem
- Persistent
s2idlemade resume usable, but the fans could keep running
